Types of double RAKE
PORTABLE
-
working width: from 5.50 to 6.40 meters
-
arms: 9+9
-
group: CMR Italy
-
springs: 54 double 10mm thick
-
wheels : 8 (10 linen)
The suspended grass catcher, with weight 900 kg, designed and manufactured by us, it meets all the requirements to become the ultimate tool of every clover grower. Flexible, fast, compact, variable length, with perfect contact on any ground, collects up to 45 acres per hour, without dropping a leaf, without taking soil with the clover, without breaking the stem.
FRONT SUSPENSION
-
working width: from 5.50 to 6.40 meters
-
arms: 9+9
-
group: CMR Italy
-
springs: 54 double 10mm thick
-
wheels : 8 (10 linen)
The mounted FRONT picker is powered by a 1000-RPM PTO, weighing 940 kg, designed and manufactured by us, it meets all the requirements to become the ultimate tool of every clover grower. Flexible, fast, compact, variable length, with perfect contact on any ground, collects up to 45 acres per hour, without dropping a leaf, without taking soil with the clover, without breaking the stem.
TRAILED 9+9 ARMS
-
working width: from 5.60 to 6.50 meters
-
arms: 9+9
-
group: CMR Italy
-
springs: 54 double 10mm thick
-
wheels: 8 on the collectors (10 linen) + 2 on the trunk
-
traction: 80 degree turn, 15 degree controllable side movement
-
lights: stop - course - turn signal (standard)
-
bottles: 4 (2 width change and 2 elevation)
A robust and versatile tool, the sliding pick-up moves exactly like the cutter, is variable width and has the ability to turn up to 80 degrees.
Its traction helps in easy turning and in the controllable independent movement of the collector in relation to the tractor. The joints of the groups constantly bring them into perfect contact with the ground. The variable arms make it capable of collecting two rows in one from a cutter width of 2.80 to 3.5 meters.
TRAILED - STEERING WHEEL - 9+9 ARMS
-
working width: from 5.60 to 6.50 meters
-
arms: 9+9
-
group: CMR Italy
-
springs: 54 double 10mm thick
-
wheels: 8 on the collectors (10 linen) + 2 on the trunk
-
traction: 80 degree turn, 15 degree controllable side movement
-
lights: stop - course - turn signal (standard)
-
bottles: 4 (2 width change and 2 elevation)
A robust and versatile tool, the sliding pick-up moves exactly like the cutter, is variable width and has the ability to turn up to 80 degrees. STEERING WHEEL TURNS THE CENTER WHEELS, for tighter turns
Its traction helps in easy turning and in the controllable independent movement of the collector in relation to the tractor. The joints of the groups constantly bring them into perfect contact with the ground. The variable arms make it capable of collecting two rows in one from a cutter width of 2.80 to 3.5 meters.
TRAILED 11+11 ARMS
-
working width: from 6.20 to 7.00 meters
-
arms: 11+11
-
group: CMR Italy
-
springs: 66 double 10mm thick
-
wheels: 8 on the collectors (10 linen) + 2 on the trunk
-
traction: 80 degree turn, 15 degree controllable side movement
-
lights: stop - course - turn signal (standard)
-
bottles: 4 (2 width change and 2 elevation)
A robust and versatile tool, the sliding picker moves exactly like the cutter, is variable width and has the ability to turn up to 80 degrees.
Its traction helps in easy turning and in the controllable independent movement of the collector in relation to the tractor. The joints of the groups constantly bring them into perfect contact with the ground. The variable arms make it capable of collecting two rows in one from a cutter width of 2.80 to 3.5 meters.
It operates at lower PTO rpm and therefore less fuel
TRAILED - STEERING WHEEL - 11+11 ARMS
-
working width: from 6.20 to 7.00 meters
-
arms: 11+11
-
group: CMR Italy
-
springs: 66 double 10mm thick
-
wheels: 8 on the collectors (10 linen) + 2 on the trunk
-
traction: 80 degree turn, 15 degree controllable side movement
-
lights: stop - course - turn signal (standard)
-
bottles: 4 (2 width change and 2 elevation)
A robust and versatile tool, the sliding pick-up moves exactly like the cutter, is variable width and has the ability to turn up to 80 degrees.STEERING WHEEL TURNS THE CENTER WHEELS, for tighter turns
Its traction helps in easy turning and in the controllable independent movement of the collector in relation to the tractor. The joints of the groups constantly bring them into perfect contact with the ground. The variable arms make it capable of collecting two rows in one from a cutter width of 2.80 to 3.5 meters. It operates at lower PTO rpm and therefore less fuel
